Product Description

The Mitsubishi System 1 Aircon MUYGP24VF2-SG1/MSYGP24VF-SG3 offers powerful cooling with a 24000 BTU capacity, perfect for large spaces. Its energy-efficient design and quiet operation make it an ideal choice for both homes and offices.

Key Features

• Energy Efficient: Achieves 4 NEA ticks for superior energy savings.

• Quiet Operation: Indoor noise levels as low as 30dB for a peaceful environment.

• Advanced Cooling: 24000 BTU capacity ensures rapid cooling for large spaces.

• Easy Maintenance: Features like Easy Clean and Dual Barrier Coating simplify upkeep.

• Environmentally Friendly: Utilizes R32 refrigerant for reduced environmental impact.

• Comprehensive Warranty: 1-year parts and 5-year compressor warranty for peace of mind.

Product Specifications

• MUYGP24VF2-SG1/MSYGP24VF-SG3

  • Function & Type: Cooling, Wall Mounted

  • Capacity (Min-Max): 6.6 (2.4-9.2) kW

  • Power Input: 1.74 kW

  • Starting Current: 7.60 A

  • Running Current: 7.60 A

  • Airflow: 9.1-13.0-14.9-20.7 CMM (m³/min)

  • Dimension (Indoor): 1100 x 238 x 325 mm

  • Dimension (Outdoor): 840 x 330 x 880 mm

  • Net Weight (Indoor): 15 kg

  • Net Weight (Outdoor): 48.5 kg

  • Indoor Sound Level (Silent-High): 30-41-45-51 dB(A)

  • Outdoor Sound Level: 57 dB(A)

  • Connection Method: Flared

  • External Piping - Gas Diameter: 12.70 mm

  • External Piping - Liquid Diameter: 6.35 mm

  • Piping Length - Max Length: 30 m

  • Piping Length - Max Height: 15 m

  • Refrigerant: R32

  • Power Supply: 230V, 1 Phase, 50Hz

  • Pre-charged Refrigerant Quantity (Max): 1.50 kg

  • Energy Labelling Scheme: i863/3194 kWh

Ideal For

This Mitsubishi System 1 Aircon is ideal for homeowners and businesses seeking efficient cooling solutions. Perfect for those who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MUYGP24VF2-SG1

• Indoor Unit: MSYGP24VF-SG3
