System 1 Aircon

Product Description

The Mitsubishi System 1 Aircon MUYGP24VF2-SG1/MSYGP24VF-SG3 offers powerful cooling with a 24000 BTU capacity, perfect for large spaces. Its energy-efficient design and quiet operation make it an ideal choice for both homes and offices.

Key Features

• Energy Efficient: Achieves 4 NEA ticks for superior energy savings.

• Quiet Operation: Indoor noise levels as low as 30dB for a peaceful environment.

• Advanced Cooling: 24000 BTU capacity ensures rapid cooling for large spaces.

• Easy Maintenance: Features like Easy Clean and Dual Barrier Coating simplify upkeep.

• Environmentally Friendly: Utilizes R32 refrigerant for reduced environmental impact.

• Comprehensive Warranty: 1-year parts and 5-year compressor warranty for peace of mind.

Product Specifications

• MUYGP24VF2-SG1/MSYGP24VF-SG3

  • Function & Type: Cooling, Wall Mounted

  • Capacity (Min-Max): 6.6 (2.4-9.2) kW

  • Power Input: 1.74 kW

  • Starting Current: 7.60 A

  • Running Current: 7.60 A

  • Airflow: 9.1-13.0-14.9-20.7 CMM (m³/min)

  • Dimension (Indoor): 1100 x 238 x 325 mm

  • Dimension (Outdoor): 840 x 330 x 880 mm

  • Net Weight (Indoor): 15 kg

  • Net Weight (Outdoor): 48.5 kg

  • Indoor Sound Level (Silent-High): 30-41-45-51 dB(A)

  • Outdoor Sound Level: 57 dB(A)

  • Connection Method: Flared

  • External Piping - Gas Diameter: 12.70 mm

  • External Piping - Liquid Diameter: 6.35 mm

  • Piping Length - Max Length: 30 m

  • Piping Length - Max Height: 15 m

  • Refrigerant: R32

  • Power Supply: 230V, 1 Phase, 50Hz

  • Pre-charged Refrigerant Quantity (Max): 1.50 kg

  • Energy Labelling Scheme: i863/3194 kWh

Ideal For

This Mitsubishi System 1 Aircon is ideal for homeowners and businesses seeking efficient cooling solutions. Perfect for those who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MUYGP24VF2-SG1

• Indoor Unit: MSYGP24VF-SG3

Discover the epitome of cooling excellence with the MITSUBISHI HV SYSTEM 1 AIRCON. With a 12000 BTU capacity, this air conditioner is perfectly suited for small to medium rooms, ensuring a consistently delightful temperature throughout.

Key Features:

• Superior Cooling: A 12000 BTU capacity ensures rapid and even cooling for your desired spaces.
• Top-notch Energy Efficiency: Holds 4 NEA Ticks, reflecting its superior energy conservation capabilities.
• 3D Auto/Quiet Air/Economy Mode: Multiple modes to cater to your specific comfort and energy-saving needs.
• 24-hr Ion Generation: Guarantees a continuous flow of purified air for a healthier environment.
• Nano Air & Allergen Clear Filter: Advanced filtration system that effectively captures allergens and pollutants.
• Hi-Power Operation: Provides maximum cooling efficiency when you need it most.

Choose the MITSUBISHI HV SYSTEM 1 AIRCON for an unmatched cooling experience, supported by Gain City's renowned expertise.

Experience the pinnacle of cooling with the MITSUBISHI HV SYSTEM 1 AIRCON SRC10YVS-W7/SRK10YVS-W7. Designed with precision and built for performance, this SYSTEM 1 AIRCON unit is a testament to Mitsubishi's commitment to quality and innovation.

Key Features:

• High Efficiency: A 1X9000 BTU capacity ensures rapid cooling for your space.
• Energy Saving: Awarded 5 NEA TICKS for its energy-efficient performance.
• Advanced Modes: Features like 3D Auto, Quiet Air, and Economy Mode ensure optimal cooling based on your preferences.
• Health Benefits: Equipped with 24-hour Ion Generators and Nano Air & Allergen Clear Filters to keep the air fresh and allergen-free.
• Powerful Performance: The Hi-Power Operation ensures consistent cooling during peak summer days.

Why Choose the MITSUBISHI HV SYSTEM 1 AIRCON from Gain City?

• Certified Technicians: BCA-certified technicians carry out all installations adhering to the highest standards.
• Customer-Centric Approach: Gain City ensures efficient and high-quality installation services focusing on customer satisfaction.

Elevate your cooling experience with the MITSUBISHI HV SYSTEM 1 AIRCON. A perfect blend of performance, efficiency, and reliability, this SYSTEM 1 AIRCON unit is a must-have for those seeking the best home comfort.

Product Description

The Mitsubishi System 1 Aircon MUYGP18VF/MSYGP18VF offers superior cooling performance with energy efficiency and quiet operation. Ideal for medium to large rooms, it ensures comfort with its sleek design and environmentally friendly refrigerant.

Key Features

• Efficient Cooling: Enjoy powerful cooling with a capacity range of 1.5 to 6.0 kW, perfect for varying room sizes.

• Energy Saving: Low power input of 1.11 kW ensures reduced electricity bills while maintaining comfort.

• Quiet Operation: Indoor sound levels as low as 29 dB(A) for a peaceful environment.

• Compact Design: Sleek indoor unit dimensions of 923x250x305mm fit seamlessly into any space.

• Environmentally Friendly: Uses R32 refrigerant, minimizing environmental impact.

• Durable Build: Robust outdoor unit with a net weight of 37 kg ensures longevity.

Product Specifications

• MUYGP18VF/MSYGP18VF

  • Function & Type: Cooling, Wall Mounted

  • Capacity (Min-Max): 4.8 (1.5-6.0) kW

  • Power Input: 1.11 kW

  • Starting Current: 5.00 A

  • Running Current: 5.00 A

  • Airflow: 6.8-9.1-12.2-14.8-18.4 CMM (m³/min)

  • Dimension (Indoor): 923x250x305 mm

  • Dimension (Outdoor): 800x285x714 mm

  • Net Weight (Indoor): 13 kg

  • Net Weight (Outdoor): 37.0 kg

  • Indoor Sound Level (Silent-High): 29-37-41-45-49 dB(A)

  • Outdoor Sound Level: 54 dB(A)

  • Connection Method: Flared

  • External Piping - Gas Diameter: 12.70 mm

  • External Piping - Liquid Diameter: 6.35 mm

  • Piping Length Max Length: 30 m

  • Piping Length - Max Height: 15 m

  • Refrigerant: R32

  • Power Supply: 230V, 1 Phase, 50Hz

  • Pre-charged Refrigerant Quantity (Max): 1.25 kg

  • Energy Labelling Scheme: i553/2050 kWh

Ideal For

This Mitsubishi System 1 Aircon is ideal for homeowners seeking efficient cooling solutions for medium to large-sized rooms. Perfect for those who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MUYGP18VF

• Indoor Unit: MSYGP18VF

Product Description

The Mitsubishi System 1 Aircon MUYGP15VF/MSYGP15VF is a top-tier air conditioning unit designed for optimal cooling performance and comfort. With its energy-efficient operation and quiet performance, it is perfect for creating a comfortable living environment. Its eco-friendly R32 refrigerant and sleek wall-mounted design make it a smart choice for modern homes.

Key Features

• Efficient Cooling: Offers a cooling capacity of 4.2 kW, ensuring your space is cooled quickly and efficiently.
• Quiet Operation: Operates at a low noise level, providing a serene environment without disturbances.
• Energy Saving: Utilizes advanced inverter technology to reduce energy consumption and save on electricity bills.
• Eco-Friendly Refrigerant: Uses R32 refrigerant, which is environmentally friendly and reduces ozone depletion.
• Compact Design: Wall-mounted design that fits seamlessly into any room without taking up floor space.
• Durable Build: Built with high-quality materials to ensure longevity and reliability.

Product Specifications

• MUY-GP15VF/MSY-GP15VF
  • Function & Type: Cooling, Wall Mounted
  • Capacity (Min-Max): 4.2 (1.5-4.8) kW
  • Power Input: 0.97 kW
  • Starting Current: 4.50 A
  • Running Current: 4.50 A
  • Airflow: 8.6-10.7-12.2-15.0-19.2 CMM (m³/min)
  • Dimension (Indoor): 923 x 250 x 305 mm
  • Dimension (Outdoor): 800 x 285 x 550 mm
  • Net Weight (Indoor): 13 kg
  • Net Weight (Outdoor): 32.0 kg
  • Indoor Sound Level (Silent-High): 28-33-38-44-49 dB(A)
  • Outdoor Sound Level: 50 dB(A)
  • Connection Method: Flared
  • External Piping - Gas Diameter: 12.70 mm
  • External Piping - Liquid Diameter: 6.35 mm
  • Piping Length - Max Length: 20 m
  • Piping Length - Max Height: 12 m
  • Refrigerant: R32
  • Power Supply: 230 V, 1 Phase, 50 Hz
  • Pre-charged Refrigerant Quantity (Max): 1.00 kg
  • Energy Labelling Scheme: i501/1857 kWh

Ideal For

This Mitsubishi System 1 Aircon is ideal for homeowners seeking efficient and quiet cooling solutions. Perfect for those who value energy-saving technology and operational comfort in their living spaces.

In the Box

• Outdoor Unit: MUY-GP15VF
• Indoor Unit: MSY-GP15VF

Product Description

The Mitsubishi System 1 Aircon MUYGP13VF/MSYGP13VF is a top choice for efficient cooling in medium-sized spaces. With its eco-friendly certification and quiet operation, it ensures comfort and sustainability. Its advanced filtration system guarantees clean air, making it perfect for health-conscious individuals.

Key Features

• Energy Efficient: Enjoy lower energy bills with its 4 Ticks eco-friendly certification.

• Quiet Operation: Experience peace and quiet with indoor sound levels as low as 21 dB(A).

• Powerful Cooling: Offers a cooling capacity of 3.5 kW, perfect for medium-sized rooms.

• Easy Maintenance: Features easy clean and dual barrier coating for hassle-free upkeep.

• Advanced Filtration: Equipped with PM2.5 filters to ensure clean and healthy air.

• Compact Design: Fits seamlessly into any room with its sleek and modern design.

Product Specifications

• MUYGP13VF/MSYGP13VF

  • Cooling Capacity: 3.5 kW (1.5 - 4.1 kW)

  • Power Input: 0.81 kW

  • Running Current: 3.80 A

  • Airflow: 6.1-18.0 CMM

  • Indoor Dimensions: 923 x 250 x 305 mm

  • Outdoor Dimensions: 800 x 285 x 550 mm

  • Indoor Net Weight: 13 kg

  • Outdoor Net Weight: 32 kg

  • Indoor Sound Level: 21-48 dB(A)

  • Outdoor Sound Level: 47 dB(A)

  • Refrigerant: R32

  • Power Supply: 230V, 1 Phase, 50Hz

  • Energy Labelling Scheme: 4 Ticks

Ideal For

The Mitsubishi System 1 Aircon MUYGP13VF/MSYGP13VF is ideal for homeowners seeking efficient cooling solutions for medium-sized rooms. Perfect for those who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MUYGP13VF

• Indoor Unit: MSYGP13VF

Product Description

The Mitsubishi System 1 Aircon MUYGP10VF/MSYGP10VF offers top-notch cooling performance with Mitsubishi Electric's latest technologies. Designed for quiet and energy-saving operation, it is perfect for small to medium-sized rooms, providing comfort and efficiency.

Key Features

• Inverter Compressor: Efficient cooling with reduced energy consumption, perfect for eco-conscious users.
• Quiet Operation: Enjoy a serene environment with minimal noise, ideal for bedrooms and study rooms.
• Eco-Friendly Refrigerant: Utilizes R32 refrigerant, ensuring a lower environmental impact.
• Wall Mounted Design: Space-saving installation suitable for various room layouts.
• Energy Efficiency: Improved EER for cost-effective cooling.
• Compact Size: Fits perfectly in small to medium-sized rooms, providing optimal comfort.

Product Specifications

• MUYGP10VF/MSYGP10VF
  • Function & Type: Cooling, Wall Mounted
  • Capacity (Min-Max): 2.5 (1.1-3.5) kW
  • Power Input: 0.51 kW
  • Starting Current: 2.70 A
  • Running Current: 2.70 A
  • Airflow: 4.3-5.4-7.2-9.3-13.6 CMM (m³/min)
  • Dimension (Indoor): 799 x 232 x 290 mm
  • Dimension (Outdoor): 800 x 285 x 550 mm
  • Net Weight (Indoor): 9 kg
  • Net Weight (Outdoor): 32 kg
  • Indoor Sound Level (Silent-High): 19-24-31-38-47 dB(A)
  • Outdoor Sound Level: 46 dB(A)
  • Connection Method: Flared
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
  • Piping Length - Max Length: 20 m
  • Piping Length - Max Height: 12 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 0.97 kg
  • Energy Labelling Scheme: i259/958 kWh

Ideal For

The Mitsubishi System 1 Aircon MUYGP10VF/MSYGP10VF is ideal for small to medium-sized rooms such as bedrooms, home offices, or small living rooms. It is perfect for those seeking quiet and energy-efficient cooling solutions.

In the Box

• Outdoor Unit: MUYGP10VF
• Indoor Unit: MSYGP10VF
