Product Description

The Mitsubishi System 4 Aircon offers a comprehensive cooling solution with its multiple indoor units and efficient outdoor unit. Ideal for homes with diverse cooling needs, it combines energy efficiency, quiet operation, and advanced technology to deliver superior comfort.

Key Features

• Energy Efficient: Designed with advanced technology to ensure high seasonal energy efficiency, saving on electricity bills.
• Quiet Operation: Enjoy a peaceful environment with low noise levels, perfect for bedrooms and living rooms.
• Flexible Installation: Suitable for various room sizes with multiple indoor units for customized cooling.
• Durable Build: Built to last with high-quality materials and robust construction.
• Advanced Airflow: Optimized airflow design for even cooling distribution across the room.
• Environmentally Friendly: Uses R32 refrigerant, which is more eco-friendly and efficient.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 1 no X 12.70 mm + 3 no X 9.52 mm
  • External Piping - Liquid Diameter: 4 no X 6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 2.00 kg
  • No. of Connectable Indoor Units: 4
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.5-12.1-14.8 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

This Mitsubishi System 4 Aircon is ideal for homeowners seeking efficient and reliable cooling solutions for multiple rooms. Perfect for families or individuals who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 1x MSXY-FP10VG, 1x MSXY-FP13VG, 2x MSXY-FP18VG

Product Description

The Mitsubishi System 4 Aircon Mxy-4h38vg/2xmsxy-fp10vg/2xmsxy-fp18vg is a top-of-the-line air conditioning system designed for both homes and businesses. With its high energy efficiency and powerful cooling capabilities, it ensures a comfortable indoor environment while saving on energy costs. Its advanced piping system and compact design make it a perfect choice for any space.

Key Features

• Energy Efficient: Save on electricity bills with the high energy efficiency of the Mitsubishi System 4 Aircon, featuring an Energy Labelling Scheme of 1790/2926kWh.

• Powerful Cooling: Enjoy a comfortable indoor climate with a cooling capacity of 8.0kW, perfect for larger spaces.

• Quiet Operation: Experience a peaceful environment with sound levels as low as 19dB(A), ensuring minimal noise disruption.

• Compact Design: The indoor units are designed to fit seamlessly into any space with dimensions of 799x232x290mm and 923x250x305mm.

• Advanced Piping System: Equipped with a flared connection method and a gas diameter of 9.52mm, ensuring efficient operation.

Product Specifications

• MXY-4H38VG

  • Capacity (Min-Max): 8.0 (1.3-10.7) kW

  • Power Supply: 230V, 1 Phase, 50Hz

  • Pre-charged Refrigerant Quantity (Max): 2.00kg

  • Dimension (WxDxH): 950x330x796mm

  • Net Weight: 58kg

  • Connection Method (Indoor/Outdoor): Flared

  • External Piping-Gas Diameter: 1noX12.7+3noX9.52mm

  • Max Length: 15m

  • Energy Labelling Scheme: 1790/2926kWh

• MSXY-FP10VG

  • Rated Cooling Capacity: 2.5kW

  • Sound Level: 19-24-29-36-45dB(A)

  • Dimension (WxDxH): 799x232x290mm

  • Net Weight: 9kg

  • External Piping-Gas Diameter: 9.52mm

  • External Piping-Liquid Diameter: 6.35mm

• MSXY-FP18VG

  • Sound Level: 28-33-38-44-49dB(A)

  • Dimension (WxDxH): 923x250x305mm

  • Net Weight: 13kg

  • External Piping-Gas Diameter: 9.52mm

  • Power Supply: 230V, 1 Phase, 50Hz

Ideal For

The Mitsubishi System 4 Aircon Mxy-4H38vg/2xmsxy-fp10vg/2xmsxy-fp18vg is ideal for homeowners and businesses looking for efficient and reliable air conditioning solutions. It's perfect for those who desire a comfortable indoor climate with energy-saving features.

In the Box

• Outdoor Unit: MXY-4H38VG

• Indoor Units: 2x MSXY-FP10VG, 2x MSXY-FP18VG

Product Description

The Mitsubishi System 4 Aircon is a versatile and efficient air conditioning solution designed for multi-room cooling. With its advanced inverter technology, it provides powerful yet energy-efficient cooling, making it ideal for both residential and commercial spaces. Its quiet operation and environmentally friendly refrigerant ensure a comfortable and sustainable cooling experience.

Key Features

• Energy Efficient: Equipped with advanced inverter technology for optimal energy savings and reduced electricity bills.
• Powerful Cooling: Offers a wide range of cooling capacities to suit different room sizes and requirements.
• Quiet Operation: Designed to operate quietly, ensuring a peaceful environment in your home or office.
• Durable Design: Built with high-quality materials for long-lasting performance and reliability.
• Easy Installation: Comes with flexible piping options for hassle-free installation.
• Environmentally Friendly: Uses R32 refrigerant, which has a lower environmental impact.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • No. of Connectable Indoor Units: 4
• MSXY-FP24VG
  • Rated Capacity: 7.1 kW
  • Power Input: 0.069 kW
  • Running Current: 0.60 A
  • Airflow Rate: 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)
  • Sound Level: 30-35-41-45-50 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.5-12.1-14.8 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg

Ideal For

This Mitsubishi System 4 Aircon is ideal for medium to large-sized homes or offices, providing efficient cooling for multiple rooms. Perfect for those seeking a reliable and energy-efficient air conditioning solution.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 2x MSXY-FP10VG, 1x MSXY-FP18VG, 1x MSXY-FP24VG

Product Description

The Mitsubishi System 4 Aircon offers a powerful and efficient cooling solution for your home. With the ability to connect up to four indoor units, it ensures consistent climate control across multiple rooms. Its compact design and quiet operation make it an ideal choice for modern living spaces.

Key Features

• High Efficiency: Achieves industry-leading seasonal energy efficiency with advanced technology and high-performance compressor.
• Multi-Room Cooling: Supports up to 4 indoor units for comprehensive climate control.
• Compact Design: Space-saving dimensions make it suitable for various installation environments.
• Quiet Operation: Low sound levels ensure a peaceful environment.
• Flexible Installation: Flared connection method and extensive piping options.
• Reliable Performance: Consistent airflow and cooling capacity for optimal comfort.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • External Piping - Gas Diameter: 1noX12.70mm + 3noX9.52mm
  • External Piping - Liquid Diameter: 4noX6.35mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • No. of Connectable Indoor Units: 4
• MSXY-FP24VG
  • Rated Capacity: 7.1 kW
  • Power Input: 0.069 kW
  • Running Current: 0.60 A
  • Airflow Rate: 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)
  • Sound Level: 30-35-41-45-50 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping - Gas Diameter: 12.70 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

The Mitsubishi System 4 Aircon is ideal for homeowners seeking efficient cooling solutions for multiple rooms. Perfect for families or individuals who desire consistent climate control across various spaces.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 2x MSXY-FP10VG, 1x MSXY-FP13VG, 1x MSXY-FP24VG

Product Description

The Mitsubishi System 4 Aircon MXY-4H38VG/2XMSXY-FP10VG/1XMSXY-FP13VG/1XMSXY-FP20 is a high-efficiency air conditioning solution perfect for homes and offices. With its advanced technology and high-performance compressor, it offers superior cooling while being energy efficient and quiet, making it an ideal choice for those seeking comfort and savings.

Key Features

• High Efficiency: The Mitsubishi System 4 Aircon offers industry-leading seasonal energy efficiency with advanced technologies and a high-performance compressor.

• Flexible Capacity: Features a variable capacity range from 1.4 to 11.6 kW, ensuring optimal cooling for different room sizes.

• Energy Saving: With a power input of just 1.62 kW, this air conditioner is designed to save energy while providing powerful cooling.

• Quiet Operation: Enjoy a peaceful environment with a sound level of just 49 dB(A), ensuring minimal noise disruption.

• Compact Design: The outdoor unit is compact with dimensions of 950 x 330 x 796 mm, making it easy to install in various spaces.

• Advanced Technology: Equipped with a high-performance compressor and R32 refrigerant for optimal energy efficiency.

Product Specifications

• MXY-4H38VG

  • Capacity (Min-Max): 8.0 (1.4-11.6) kW

  • Power Input: 1.62 kW

  • Starting Current: 7.22 A

  • Running Current: 7.22 A

  • Airflow: 8.0 CMM (m³/min)

  • Dimension: 950 x 330 x 796 mm

  • Connection Method (Indoor/Outdoor): Flared

  • External Piping - Gas Diameter: 1 no X 12.70 mm + 3 no X 9.52 mm

  • External Piping - Liquid Diameter: 4 no X 6.35 mm

  • Max Piping Length (Each): 25 m

  • Max Piping Length (Total): 70 m

  • Refrigerant: R32

  • Net Weight: 58 kg

  • Power Supply: 1790/2926 kWh

  • Number of Connectable Indoor Units: 4

• MSXY-FP10VG

  • Rated Capacity: 2.8 kW

  • Power Input: 0.028 kW

  • Running Current: 0.27 A

  • Airflow Rate: 4.1-5.1-6.3-9.5 CMM (m³/min)

  • Net Weight: 9 kg

  • External Piping - Gas Diameter: 9.52 mm

  • External Piping - Liquid Diameter: 6.35 mm

• MSXY-FP13VG

  • Rated Capacity: 3.5 kW

  • Power Input: 0.036 kW

  • Running Current: 0.33 A

  • Airflow Rate: 4.1-5.1-6.3-9.1 CMM (m³/min)

  • Net Weight: 9 kg

  • External Piping - Gas Diameter: 9.52 mm

  • External Piping - Liquid Diameter: 6.35 mm

• MSXY-FP20VG

  • Rated Capacity: 6.0 kW

  • Power Input: 0.059 kW

  • Running Current: 0.52 A

  • Airflow Rate: 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)

  • Sound Level: 30-35-41-45-50 dB(A)

  • Dimension (WxDxH): 923x250x305 mm

  • Net Weight: 13 kg

  • External Piping - Gas Diameter: 12.70 mm

  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

The Mitsubishi System 4 Aircon is ideal for homes and offices seeking efficient and reliable cooling solutions with multiple indoor units for different rooms.

In the Box

• Outdoor Unit: MXY-4H38VG

• Indoor Unit: 2x MSXY-FP10VG

• Indoor Unit: 1x MSXY-FP13VG

• Indoor Unit: 1x MSXY-FP20VG

Product Description

The Mitsubishi System 4 Air Conditioner offers a powerful cooling solution for multiple rooms. With its energy-efficient inverter technology, quiet operation, and advanced filtration system, it ensures comfort and clean air in your home.

Key Features

• Energy Efficient: Equipped with inverter technology, this air conditioner adjusts cooling capacity for optimal energy savings.
• Quiet Operation: Enjoy peace and quiet with sound levels as low as 19dB.
• Advanced Filtration: PM 2.5 filter ensures clean and healthy air circulation.
• Dual Barrier Coating: Protects against dust and oil build-up, ensuring longevity.
• Easy Maintenance: Features a detachable panel for hassle-free cleaning.
• Flexible Installation: Connects up to 4 indoor units for versatile cooling solutions.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • No. of Connectable Indoor Units: 4
• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.5-12.1-14.8 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg

Ideal For

This Mitsubishi System 4 Air Conditioner is ideal for homeowners seeking efficient cooling solutions for multiple rooms. Perfect for those who value quiet operation and energy efficiency.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 2x MSXY-FP10VG, 1x MSXY-FP13VG, 1x MSXY-FP18VG
• Remote Controls
• Installation Manual
• Warranty Card

Product Description

The Mitsubishi System 4 Aircon offers a powerful and efficient cooling solution for multiple rooms. With advanced inverter technology, it ensures energy savings and quiet operation, making it perfect for modern homes.

Key Features

• Energy Efficient: Utilizes advanced inverter technology for reduced energy consumption.
• Multi-room Cooling: Supports up to four indoor units for comprehensive cooling coverage.
• Quiet Operation: Designed to minimize noise, ensuring a peaceful environment.
• Compact Design: Sleek and space-saving units fit seamlessly into any room.
• Advanced Airflow: Optimized airflow settings for consistent and comfortable cooling.
• Durable Build: Built with high-quality materials for long-lasting performance.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 1noX12.70mm + 3noX9.52mm
  • External Piping - Liquid Diameter: 4noX6.35mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 2.00 kg
  • No. of Connectable Indoor Units: 4
  • Energy Labelling Scheme: 1790/2926 kWh
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

The Mitsubishi System 4 Aircon is ideal for homeowners seeking efficient cooling solutions for multiple rooms. Perfect for families or individuals who value energy efficiency and advanced technology in air conditioning.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 2x MSXY-FP10VG, 2x MSXY-FP13VG

Product Description

The Mitsubishi System 4 Aircon MXY-4H38VG/3XMSXY-FP10VG/1XMSXY-FP24VG offers a powerful and efficient cooling solution for multiple rooms. With its advanced technology, it ensures energy efficiency and quiet operation, making it perfect for family homes. Its sleek design and flexible installation options make it a versatile choice for any home decor.

Key Features

• Energy Efficient: Designed to achieve industry-leading seasonal energy efficiency with advanced technology and high-performance compressors.
• Quiet Operation: Enjoy a peaceful environment with sound levels as low as 19dB(A) for indoor units.
• Flexible Installation: Connect up to 4 indoor units with a maximum piping length of 70m, offering versatile installation options.
• Powerful Cooling: Provides a cooling capacity of up to 11.6kW, ensuring comfort even in larger spaces.
• Compact Design: Sleek and compact indoor units that blend seamlessly into any room decor.
• Advanced Airflow: Optimized airflow rates for efficient cooling distribution throughout the room.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 1noX12.70mm + 3noX9.52mm
  • External Piping - Liquid Diameter: 4noX6.35mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 2.00 kg
  • No. of Connectable Indoor Units: 4
• MSXY-FP24VG
  • Rated Capacity: 7.1 kW
  • Power Input: 0.069 kW
  • Running Current: 0.60 A
  • Airflow Rate: 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)
  • Sound Level: 30-35-41-45-50 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping - Gas Diameter: 12.70 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

The Mitsubishi System 4 Aircon is ideal for homeowners seeking efficient and powerful cooling solutions for multiple rooms. Perfect for families or individuals who value energy efficiency and quiet operation in their air conditioning systems.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 3x MSXY-FP10VG, 1x MSXY-FP24VG

Product Description

The Mitsubishi System 4 Aircon Mxy-4h38vg/3xmsxy-fp10vg/1xmsxy-fp20vg is a high-performance air conditioning solution designed for those who seek energy efficiency and powerful cooling across multiple rooms. With its advanced inverter technology and use of R32 refrigerant, it ensures optimal cooling while being environmentally friendly. Ideal for both residential and commercial spaces, this system provides a comfortable and quiet environment.

Key Features

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.0 m³/min
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 220-240V, 50Hz
  • External Piping - Gas Diameter: 1no X 12.70 mm + 3no X 9.52 mm
  • External Piping - Liquid Diameter: 4no X 6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Net Weight: 58 kg
  • Outdoor Sound Level: 49 dB(A)

Ideal For

The Mitsubishi System 4 Aircon Mxy-4H38vg/3Xmsxy-Fp10vg/1Xmsxy-Fp20vg is ideal for those seeking a reliable and efficient cooling solution for their home or office. Perfect for maintaining a comfortable environment in multiple rooms, this air conditioner is designed for those who value energy efficiency and superior cooling performance.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 3x MSXY-FP10VG
• Indoor Unit: 1x MSXY-FP20VG

Product Description

The Mitsubishi System 4 Aircon offers a comprehensive cooling solution with its advanced inverter technology and eco-friendly R32 refrigerant. Designed for quiet operation and energy efficiency, it ensures a comfortable indoor climate across multiple rooms, making it perfect for family homes.

Key Features

• Energy Efficient: Equipped with advanced inverter technology for reduced energy consumption and lower electricity bills.
• Powerful Cooling: Delivers a robust cooling capacity to maintain a comfortable indoor environment even during the hottest days.
• Quiet Operation: Designed to operate quietly, ensuring a peaceful and undisturbed living space.
• Flexible Installation: Multiple indoor units allow for versatile installation options to suit different room layouts.
• Durable Build: Built with high-quality materials to ensure long-lasting performance and reliability.
• Eco-Friendly Refrigerant: Utilizes R32 refrigerant, which has a lower environmental impact.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • No. of Connectable Indoor Units: 4
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.5-12.1-14.8 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg

Ideal For

The Mitsubishi System 4 Aircon is ideal for homeowners seeking efficient and reliable cooling solutions for multiple rooms. Perfect for families or individuals who desire a comfortable and consistent indoor climate.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 3x MSXY-FP10VG, 1x MSXY-FP18VG

Product Description

The Mitsubishi System 4 Aircon is a top-tier air conditioning solution designed for efficiency and comfort. With its advanced inverter technology, it ensures energy savings while providing powerful cooling across multiple rooms. Ideal for large spaces, it operates quietly and fits seamlessly into any modern decor.

Key Features

• Energy Efficient: Utilizes advanced inverter technology to reduce energy consumption.
• Quiet Operation: Designed to operate at low noise levels for a peaceful environment.
• Compact Design: Sleek and modern design fits seamlessly into any space.
• Powerful Cooling: Capable of cooling large areas quickly and efficiently.
• Easy Installation: Comes with a flexible piping system for hassle-free setup.
• Durable Build: Built with high-quality materials for long-lasting performance.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 1noX12.70mm + 3noX9.52mm
  • External Piping - Liquid Diameter: 4noX6.35mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 2.00 kg
  • No. of Connectable Indoor Units: 4
  • Energy Labelling Scheme: 1790/2926 kWh
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

The Mitsubishi System 4 Aircon is ideal for large homes or offices that require efficient cooling across multiple rooms. Perfect for those seeking energy-efficient and powerful air conditioning solutions.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 3x MSXY-FP10VG, 1x MSXY-FP13VG

Product Description

The Mitsubishi System 4 Aircon MXY-4H38VG/4XMSXY-FP10VG is a versatile and efficient cooling solution designed for medium to large spaces. With its high energy efficiency, quiet operation, and flexible installation options, it is perfect for both residential and commercial use.

Key Features

• High Efficiency: Achieve optimal cooling with a capacity range of 8.0 kW, perfect for varying room sizes.
• Energy Saving: Equipped with an energy-efficient compressor, reducing electricity consumption significantly.
• Quiet Operation: Enjoy a peaceful environment with a low noise level of 49 dB(A).
• Flexible Installation: Supports up to 4 indoor units, allowing for versatile placement options.
• Advanced Refrigerant: Utilizes R32 refrigerant for superior cooling performance and environmental friendliness.
• Robust Design: Durable construction with a net weight of 58 kg, ensuring long-lasting performance.

Product Specifications

• MXY-4H38VG
  • Capacity (Min-Max): 8.0 (1.4-11.6) kW
  • Power Input: 1.62 kW
  • Starting Current: 7.22 A
  • Running Current: 7.22 A
  • Airflow: 59.2 CMM (m³/min)
  • Dimension (WxDxH): 950x330x796 mm
  • Net Weight: 58 kg
  • Outdoor Sound Level: 49 dB(A)
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 1no x 12.70 mm + 3no x 9.52 mm
  • External Piping - Liquid Diameter: 4no x 6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 2.00 kg
  • No. of Connectable Indoor Units: 4
  • Energy Labelling Scheme: 1790/2926 kWh
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

This Mitsubishi System 4 Aircon is ideal for medium to large spaces, perfect for homes and offices seeking efficient cooling solutions with multiple indoor units.

In the Box

• Outdoor Unit: MXY-4H38VG
• Indoor Units: 4x MSXY-FP10VG

Product Description

The Mitsubishi System 4 Aircon MXY-4H33VG/3XMSXY-FP10VG/1XMSXY-FP13VG offers a perfect blend of efficiency and performance. Designed for multi-room cooling, it features advanced inverter technology for energy savings and quiet operation. Ideal for both residential and small office spaces, this air conditioner ensures comfort and reliability with its durable build and sleek design.

Key Features

• Energy Efficiency: Equipped with advanced inverter technology, this air conditioner ensures optimal energy savings and reduced electricity bills.
• Quiet Operation: Enjoy a peaceful environment with low noise levels, perfect for bedrooms and study rooms.
• Multi-Room Cooling: Capable of cooling multiple rooms simultaneously, ideal for homes and small offices.
• Compact Design: Sleek and modern design that blends seamlessly with any interior decor.
• Durable Build: Built with high-quality materials for long-lasting performance and reliability.
• Easy Installation: Designed for hassle-free installation with flexible piping options.

Product Specifications

• MXY-4H33VG
  • Capacity (Min-Max): 6.9 (1.3-10.7) kW
  • Power Input: 1.42 kW
  • Starting Current: 6.37 A
  • Running Current: 6.37 A
  • Airflow: 38.7 CMM (m³/min)
  • Dimension (WxDxH): 840x330x710 mm
  • Net Weight: 56 kg
  • Outdoor Sound Level: 49 dB(A)
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 1noX12.70mm + 3noX9.52mm
  • External Piping - Liquid Diameter: 4noX6.35mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 70 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 1.85 kg
  • No. of Connectable Indoor Units: 4
  • Energy Labelling Scheme: i714/2646 kWh
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP10VG
  • Rated Capacity: 2.8 kW
  • Power Input: 0.028 kW
  • Running Current: 0.27 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)
  • Sound Level: 19-24-29-36-45 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

This Mitsubishi System 4 Aircon is ideal for homeowners looking to efficiently cool multiple rooms with a single outdoor unit. Perfect for families or small offices seeking energy-efficient and reliable air conditioning solutions.

In the Box

• Outdoor Unit: MXY-4H33VG
• Indoor Units: 3x MSXY-FP10VG, 1x MSXY-FP13VG

Product Description

The Mitsubishi System 4 Aircon MXY-4H33VG/4XMSXY-FP10VG offers a perfect blend of energy efficiency and powerful cooling. Ideal for both residential and commercial spaces, it ensures quiet operation and flexible installation options.

Key Features

• Energy Efficient: Designed to achieve industry's leading seasonal energy efficiency with advanced technology.

• Quiet Operation: Enjoy a peaceful environment with sound levels as low as 19 dB(A).

• Compact Design: Space-saving design with dimensions of 799x232x290mm for indoor units.

• Powerful Cooling: Rated capacity of 2.8kW ensures effective cooling even in larger spaces.

• Flexible Installation: Supports multiple indoor units for versatile cooling solutions.

• Durable Build: High-performance compressor ensures long-lasting reliability.

Product Specifications

• MSXY-FP10VG

  • Rated Capacity: 2.8kW

  • Power Input: 0.028kW

  • Running Current: 0.27A

  • Airflow Rate: 4.1-5.1-6.3-9.1-12.9 CMM (m³/min)

  • Sound Level: 19-24-29-36-45 dB(A)

  • Dimension (WxDxH): 799x232x290 mm

  • Net Weight: 9 kg

  • External Piping - Gas Diameter: 9.52 mm

  • External Piping - Liquid Diameter: 6.35 mm

• MXY-4H33VG

  • Capacity (Min-Max): 6.9 (1.3-10.7) kW

  • Power Input: 1.42 kW

  • Full Load COP: 4.86

  • Weighted COP: 5.76

  • Running Current: 6.37 A

  • Airflow: 38.7 CMM (m³/min)

  • Dimension (WxDxH): 840x330x710 mm

  • Net Weight: 55 kg

  • Outdoor Sound Level: 49 dB(A)

  • External Piping - Gas Diameter: 1noX12.7+3noX9.52 mm

  • External Piping - Liquid Diameter: 4noX6.35 mm

Ideal For

This Mitsubishi System 4 Aircon is ideal for homes and offices looking for efficient cooling solutions. Perfect for those who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MXY-4H33VG

• Indoor Units: 4x MSXY-FP10VG

Product Description

The Mitsubishi System 3 Air Conditioner offers a perfect blend of efficiency and style. With its advanced inverter technology, it provides powerful cooling while minimizing energy consumption. Ideal for multi-room cooling, it ensures a comfortable environment with quiet operation and a sleek design.

Key Features

• Energy Efficient: Enjoy lower energy bills with advanced inverter technology that optimizes power consumption.
• Quiet Operation: Experience peace and quiet with sound levels as low as 19 dB(A) for a serene environment.
• Compact Design: Sleek and modern design fits seamlessly into any room decor.
• Powerful Cooling: High airflow rates ensure rapid cooling even on the hottest days.
• Easy Installation: Flared connection method simplifies setup and maintenance.
• Environmentally Friendly: Uses R32 refrigerant for reduced environmental impact.

Product Specifications

• MXY-3H28VG
  • Capacity (Min-Max): 6.5 (1.3-8.9) kW
  • Power Input: 1.33 kW
  • Starting Current: 5.93 A
  • Running Current: 5.93 A
  • Airflow: 38.7 CMM (m³/min)
  • Dimension (WxDxH): 840x330x710 mm
  • Net Weight: 55 kg
  • Outdoor Sound Level: 49 dB(A)
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping-Gas Diameter: 9.52 mm
  • External Piping-Liquid Diameter: 6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 60 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 1.65 kg
  • No. of Connectable Indoor Units: 3
• MSXY-FP24VG
  • Rated Capacity: 7.1 kW
  • Power Input: 0.069 kW
  • Running Current: 0.60 A
  • Airflow Rate: 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)
  • Sound Level: 30-35-41-45-50 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping-Gas Diameter: 12.70 mm
  • External Piping-Liquid Diameter: 6.35 mm
• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.5-12.1-14.8 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping-Gas Diameter: 9.52 mm
  • External Piping-Liquid Diameter: 6.35 mm
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping-Gas Diameter: 9.52 mm
  • External Piping-Liquid Diameter: 6.35 mm

Ideal For

This Mitsubishi System 3 Air Conditioner is ideal for homeowners looking for efficient cooling solutions for multiple rooms. Perfect for families or individuals who want to maintain a comfortable indoor environment.

In the Box

• Outdoor Unit: MXY-3H28VG
• Indoor Units: 1x MSXY-FP13VG, 1x MSXY-FP18VG, 1x MSXY-FP24VG

Product Description

The Mitsubishi System 3 Aircon MXY-3H28VG/1XMSXY-FP13VG/1XMSXY-FP18VG/1XMSXY-FP20 is a versatile and energy-efficient air conditioning solution perfect for cooling multiple rooms. With advanced airflow control and environmentally friendly refrigerant, it ensures optimal comfort and sustainability.

Key Features

• Energy Efficient: Equipped with an Energy Labelling Scheme of i653/2418kWh, this air conditioner ensures efficient energy consumption.
• Powerful Cooling: The MITSUBISHI SYSTEM 3 AIRCON offers a wide range of cooling capacities, making it suitable for different room sizes and ensuring comfort in every corner.
• Advanced Airflow Control: With adjustable airflow rates, you can customize the cooling experience to your preference, ensuring optimal comfort.
• Environmentally Friendly: Utilizes R32 refrigerant, which is known for its lower environmental impact compared to traditional refrigerants.
• Compact and Lightweight Design: The indoor units are designed to be compact and lightweight, making them easy to install and maintain.
• Reliable Performance: MITSUBISHI's reputation for quality ensures long-lasting performance and durability.

Product Specifications

• MXY-3H28VG
  • Capacity (Min-Max): 6.5 (1.3-8.9) kW
  • Power Input: 1.33 kW
  • Starting Current: 5.93 A
  • Running Current: 5.93 A
  • Airflow: 38.7 CMM (m³/min)
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 60 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 1.65 kg
  • No. of Connectable Indoor Units: 3
  • Outdoor Sound Level: 49 dB(A)
  • Dimension (WxDxH): 800x330x710 mm
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • External Piping-Gas Diameter: 9.52 mm
  • External Piping-Liquid Diameter: 6.35 mm
• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.1-14.1 CMM (m³/min)
  • External Piping-Gas Diameter: 9.52 mm
  • External Piping-Liquid Diameter: 6.35 mm

  MSXY-FP20VG

  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.1-14.1 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • External Piping-Gas Diameter: 9.52 mm
  • External Piping-Liquid Diameter: 6.35 mm

Ideal For

The MITSUBISHI SYSTEM 3 AIRCON MXY-3H28VG/1XMSXY-FP13VG/1XMSXY-FP18VG/1XMSXY-FP20 is ideal for homeowners seeking efficient and reliable cooling solutions for multiple rooms. Perfect for families and individuals who value energy efficiency and comfort in their living spaces.

In the Box

• Outdoor Unit: MXY-3H28VG
• Indoor Units: 1x MSXY-FP13VG, 1x MSXY-FP18VG, 1x MSXY-FP20VG

Product Description

The MXY-3H28VG/1XMSXY-FP13VG/2XMSXY-FP18VG System 3 Aircon by Mitsubishi is designed to provide efficient and powerful cooling for your home. With a sleek and compact design, it fits seamlessly into any modern living space. The air conditioner features advanced technology for optimal energy efficiency, ensuring a comfortable environment while minimizing energy consumption. Ideal for homes looking to maintain a cool and eco-friendly atmosphere.

Key Features

• Energy Efficient: The MXY-3H28VG System 3 Aircon is designed to provide maximum cooling while minimizing energy consumption, making it an eco-friendly choice for your home.
• Powerful Cooling: With a rated capacity of 5.0kW, this air conditioner delivers powerful cooling to keep your space comfortable even during the hottest days.
• Quiet Operation: Enjoy a peaceful environment with sound levels ranging from 28 to 49 dB(A), ensuring minimal noise disruption.
• Advanced Airflow Control: The unit offers adjustable airflow rates from 4.1 to 38.7 CMM, allowing you to customize the cooling experience to your preference.
• Compact Design: The indoor units, MSXY-FP13VG and MSXY-FP18VG, feature a sleek and compact design that fits seamlessly into any room decor.

Product Specifications

• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.5-12.1-14.8 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MXY-3H28VG
  • Capacity (Min-Max): 6.5 (1.3-8.9) kW
  • Power Input: 1.33 kW
  • Starting Current: 5.93 A
  • Running Current: 5.93 A
  • Airflow: 38.7 CMM (m³/min)
  • Dimension (WxDxH): 840x330x710 mm
  • Net Weight: 55 kg
  • Outdoor Sound Level: 49 dB(A)
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 3noX9.52 mm
  • External Piping - Liquid Diameter: 3noX6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 60 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 1.65 kg (1.65 kg)
  • No. of Connectable Indoor Units: 3
  • Energy Labelling Scheme: i653/2418 kWh
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

The MXY-3H28VG/1XMSXY-FP13VG/2XMSXY-FP18VG System 3 Aircon is ideal for homeowners seeking efficient cooling solutions for multiple rooms. Perfect for families and individuals who desire a comfortable and energy-efficient environment.

In the Box

• Outdoor Unit: MXY-3H28VG
• Indoor Units: 1x MSXY-FP13VG, 2x MSXY-FP18VG

Product Description

The Mitsubishi System 3 Aircon offers a perfect blend of efficiency and comfort, ideal for cooling multiple rooms in your home or office. With its energy-efficient design and quiet operation, it ensures a pleasant environment while saving on energy costs.

Key Features

• Energy Efficient: Designed to minimize energy consumption while delivering powerful cooling.
• Quiet Operation: Enjoy a peaceful environment with low noise levels during operation.
• Multi-Room Cooling: Capable of cooling multiple rooms simultaneously, perfect for homes and offices.
• Compact Design: Sleek and compact units that fit seamlessly into any space.
• Advanced Airflow: Optimized airflow for consistent and comfortable cooling.
• Durable Build: Built with high-quality materials for long-lasting performance.

Product Specifications

• MXY-3H28VG
  • Capacity (Min-Max): 6.5 (1.3-8.9) kW
  • Power Input: 1.33 kW
  • Starting Current: 5.93 A
  • Running Current: 5.93 A
  • Airflow: 38.7 CMM (m³/min)
  • Dimension (WxDxH): 840x330x710 mm
  • Net Weight: 55 kg
  • Outdoor Sound Level: 49 dB(A)
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 3x 9.52 mm
  • External Piping - Liquid Diameter: 3x 6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 60 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 1.65 kg
  • No. of Connectable Indoor Units: 3
• MSXY-FP24VG
  • Rated Capacity: 7.1 kW
  • Power Input: 0.069 kW
  • Running Current: 0.60 A
  • Airflow Rate: 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)
  • Sound Level: 30-35-41-45-50 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping - Gas Diameter: 12.70 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

The Mitsubishi System 3 Aircon is ideal for medium to large-sized homes or offices, providing efficient cooling for multiple rooms. Perfect for those who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MXY-3H28VG
• Indoor Units: 2x MSXY-FP13VG
• Indoor Unit: 1x MSXY-FP24VG

Product Description

The Mitsubishi System 3 Aircon offers a perfect blend of efficiency and comfort, ideal for cooling multiple rooms in your home. With its energy-saving features and quiet operation, it ensures a pleasant environment without high electricity bills. Its sleek design complements any interior, making it a smart choice for modern households.

Key Features

• Energy Efficient: Designed to provide optimal cooling while minimizing energy consumption, making it cost-effective for long-term use.
• Quiet Operation: Enjoy a peaceful environment with low noise levels, perfect for bedrooms and living rooms.
• Advanced Airflow: Equipped with adjustable airflow settings to ensure even distribution of cool air throughout the room.
• Compact Design: Sleek and modern design that fits seamlessly into any home decor.
• Durable Build: Built with high-quality materials to ensure longevity and reliability.
• Easy Installation: Comes with a straightforward installation process, reducing setup time and effort.

Product Specifications

• MXY-3H28VG
  • Capacity (Min-Max): 6.5 (1.3-8.9) kW
  • Power Input: 1.33 kW
  • Starting Current: 5.93 A
  • Running Current: 5.93 A
  • Airflow: 38.7 CMM (m³/min)
  • Dimension (WxDxH): 840x330x710 mm
  • Net Weight: 55 kg
  • Outdoor Sound Level: 49 dB(A)
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping-Gas Diameter: 3x9.52 mm
  • External Piping-Liquid Diameter: 3x6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 60 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50 Hz
  • Pre-charged Refrigerant Quantity (Max): 1.65 kg
  • No. of Connectable Indoor Units: 3
• MSXY-FP20VG
  • Rated Capacity: 6.0 kW
  • Power Input: 0.059 kW
  • Running Current: 0.52 A
  • Airflow Rate: 9.3-11.1-13.7-16.1-20.0 CMM (m³/min)
  • Sound Level: 30-35-41-45-50 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping-Gas Diameter: 12.70 mm
  • External Piping-Liquid Diameter: 6.35 mm
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping-Gas Diameter: 9.52 mm
  • External Piping-Liquid Diameter: 6.35 mm

Ideal For

This Mitsubishi System 3 Aircon is ideal for homeowners seeking efficient cooling solutions for multiple rooms. Perfect for families or individuals who desire a comfortable and energy-efficient environment.

In the Box

• Outdoor Unit: MXY-3H28VG
• Indoor Units: 2x MSXY-FP13VG
• Indoor Unit: 1x MSXY-FP20VG

Product Description

The Mitsubishi System 3 Aircon offers superior cooling performance for multiple rooms. With its energy-efficient design and quiet operation, it's perfect for creating a comfortable home environment. Its sleek, compact design ensures it fits seamlessly into any space.

Key Features

• Energy Efficient: Designed to minimize power consumption while maximizing cooling performance.
• Quiet Operation: Enjoy a peaceful environment with low sound levels during operation.
• Multi-room Cooling: Efficiently cools multiple rooms with its System 3 configuration.
• Compact Design: Fits seamlessly into any space with its sleek and compact design.
• Advanced Airflow: Provides optimal air distribution for consistent comfort.
• Durable Build: Built to last with high-quality materials and construction.

Product Specifications

• MXY-3H28VG
  • Capacity (Min-Max): 6.5 (1.3-8.9) kW
  • Power Input: 1.33 kW
  • Starting Current: 5.93 A
  • Running Current: 5.93 A
  • Airflow: 38.7 CMM (m³/min)
  • Dimension (WxDxH): 840x330x710 mm
  • Net Weight: 55 kg
  • Outdoor Sound Level: 49 dB(A)
  • Connection Method (Indoor/Outdoor): Flared
  • External Piping - Gas Diameter: 3x 9.52 mm
  • External Piping - Liquid Diameter: 3x 6.35 mm
  • Max Piping Length (Each): 25 m
  • Max Piping Length (Total): 60 m
  • Max Height Difference: 15 m
  • Refrigerant: R32
  • Power Supply: 230V, 1 Phase, 50Hz
  • Pre-charged Refrigerant Quantity (Max): 1.65 kg
  • No. of Connectable Indoor Units: 3
  • Energy Labelling Scheme: i653/2418 kWh
• MSXY-FP13VG
  • Rated Capacity: 3.5 kW
  • Power Input: 0.036 kW
  • Running Current: 0.33 A
  • Airflow Rate: 4.1-5.1-6.3-9.1-14.1 CMM (m³/min)
  • Sound Level: 19-24-30-36-47 dB(A)
  • Dimension (WxDxH): 799x232x290 mm
  • Net Weight: 9 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm
• MSXY-FP18VG
  • Rated Capacity: 5.0 kW
  • Power Input: 0.042 kW
  • Running Current: 0.38 A
  • Airflow Rate: 6.2-7.7-9.5-12.1-14.8 CMM (m³/min)
  • Sound Level: 28-33-38-44-49 dB(A)
  • Dimension (WxDxH): 923x250x305 mm
  • Net Weight: 13 kg
  • External Piping - Gas Diameter: 9.52 mm
  • External Piping - Liquid Diameter: 6.35 mm

Ideal For

This Mitsubishi System 3 Aircon is ideal for homeowners seeking efficient cooling solutions for multiple rooms. Perfect for families or individuals who value energy efficiency and quiet operation.

In the Box

• Outdoor Unit: MXY-3H28VG
• Indoor Units: 2x MSXY-FP13VG
• Indoor Unit: 1x MSXY-FP18VG
